Assomac Machines Limited

Wire Coiler Packing Machine

We are leading manufacturers of Wire Coiler Packing Machine.

SALIENT FEATURES:

  • Automatic wrapping machine capable of wrapping large range of OD & ID of coils.
  • Multiple coils can be wrapped using one roll of wrapping material.
  • Unwrapping or winding back possible.
  • Variable overlap of packing material possible through speed control as per requirements.
  • The machine height is adjustable for different OD & ID of the Coils.
  • Packing Tape tension is adjustable.
  • Automatic cutting of tape after coil length completion.
  • Pneumatic draw out of coils after completion.
Wire Coiler Packing Machine

Specification:

Model No. AML WR-400 AML WR-500 AML WR-800
Metal width < 400 mm < 500mm < 800mm
Metal OD < 1500 mm < 1600 mm < 1800mm
Metal ID > 508mm > 508mm > 508mm
Packing material W:90mm ID:54mm OD: 600mm W:90mm ID:54mm OD: 600mm W:90mm ID:54mm OD: 600mm
Roller Speed 2.5m/min 2.5m/min 2.5m/min
Rotating Speed 50r/min 50r/min 30r/min
Roller loading 3000 Kg 4000 Kg 8000 Kg
Power output 7.5 HP 10 HP 15 HP

Wire Coiler Packing Machine
Wire Coiler Packing Machine
Wire Coiler Packing Machine
